the Si9000e Insertion Loss Field Solver is designed to model transmission line loss, impedance at given frequencies and extract full transmission line parameters over a wide range of popular PCB transmission lines (over 100 structures). Employing boundary element method field solving, the Si9000e extracts RLGC matrices and rapidly plots a range of transmission line information for the structure you are designing. Available versions: 25.x , 22.x ,… Polar Instruments Si9000e 2025 v25.01 Tested Picture Loss is graphed three ways with clear indication of dielectric, copper and total loss and includes Huray / Canonball /Gradient plus legacy Hammerstad, & Groisse methods for roughness modeling: Links with Speedstack as Speedstack Si Si Crosstalk option – Multiline and differential pair (lossless) crosstalk – models coupling between...

Speedstack PCB (Speedstack+Si8000m)stackup design tool is a packaged combination of the Si8000m field solving impedance calculator and the Speedstack professional layer PCB stackup design system. If you need both impedance calculation and layer stackup/build up documentation the Speedstack PCB offers a considerable saving over purchasing separate licenses. Available versions: 22.x ,20.x ,… Polar Instruments Speedstack PCB 2022 v22.04 Tested Picture For PCB fabricators, Speedstack PCB interfaces with the industry standard Polar Si8000m PCB Controlled Impedance Field Solver. It includes a link and license for Polar’s Si8000m, using the proven Polar Si8000m multiple dielectric boundary element field solver to provide the impedance data for the stack. Ideal for both rigid and flex-rigid stackups Speedstack PCB allows OEM designers to create accurate...

Speedstack Si(Speedstack+Si9000e) insertion loss controlled PCB stackup design tool is made for you if you are a designer, fabricator or PCB technologist who needs to manage PCB stackups with both impedance and insertion loss control. In addition to incorporating Polars proven insertion loss field solver capability, Speedstack Si allows rapid import and export of insertion loss projects into the Si9000e insertion loss field solver so you can analyse your stack up design in detail. Available versions: 22.x ,20.x ,… Polar Instruments Speedstack PCB 2022 v22.04 Tested Picture Speedstack Si delivers rich reporting capability and not only generates the stackup material data but also graphs predicted insertion loss characteristics – including industry standard modeling for roughness using Hammerstad, Groisse and Cannonball-Huray methods....

The Si8000m is a boundary element method field solver that builds on the familiar easy to use user interface in earlier Polar impedance design systems. The Si8000m adds enhanced modelling to predict the finished impedance of multiple dielectric PCB builds and also takes into account the local variations in dielectric constant on close spaced differential structures. The Si8000m assumes negligible insertion loss in the transmission line; should you wish to model insertion loss the Si9000e adds extensive insertion loss modeling capabilities Available versions: 22.x ,20.x ,… Polar Instruments Si8000m 2022 v22.04 Tested Picture Si8000m – comprehensive modeling of over 100 structures Surface coating is often overlooked when modelling and the Si8000m models the resist thickness adjacent to above and between...
