CABINET VISION is the industry leading software tool for the cabinet & joinery industry. Our software will help enable any furniture, commercial fit-out or cabinet manufacturer to fully automate and integrate their design through to manufacturing processes.
Available other versions: 2024.x ,2023.x
Hexagon CABINET VISION 2025.1 Tested Picture
There are some great new features we hope you can take advantage of to improve your usage of CABINET VISION.
Here are a few of the highlights:
- Major performance improvements when going from CV to S2M CENTER
- Modify Construction Methods per Assembly
- Modify Material Schedules per Assembly
- Apply Connections to any Edge
- Reorder Rooms
- New from the ground up, simplified installation
- What’s New Start Up Tips
- Redesigned Welcome Screen
- Redesigned Sidebar Properties
What’s New is CABINET VISION 2025.1
Assembly Level
- Modify Construction Method per Assembly
- Modify Material Schedule per Assembly
- Control Slat Width for Slat Doors in Door Section Editor
- Control Minimum Width and Height of Shoe Section in Section Editor
General
- Sidebar in Light Editor restyled and re-sizable
- Brightness sliders in Lighting Utility single click movement
- Sidebar in Camera Editor restyled and re-sizable
- Constraint annotation position saved –
- Export PNC updated to PNX (SQL LocalDB)
- Simplified Style selection for user interface to Light and Dark
- Start-up Tips window at application startup
- Welcome Screen look and feel update
- Home and Object Tree sidebar tab hot keys
- Simplified Backup Utility selections
- Move System items from Reports.mdf to CVData.mdf
- Simplified Installation
- MSSQL Engine updated to Version 2022
Parts
- Apply Connections to any edge
- Connections global search for parts
Reports
- Combit List and Label Report engine updated to Version 30
Room Level
- Reorder Rooms
- Countertop Properties: Construction and Materials sorted alphabetically –
- Splash Properties: Materials sorted alphabetically –
- Set a specific Soffit Height in the Modify Wall Height Utility
User Created Standards
- Option to disable IntelliSense in UCS Editor
- GetChildren() and GetChildren(string filter) Method
Whats New in SCREEN 2 MACHINE 2025.1
General
- Felder F4 Label Applicator
- Support for Blum BXF2 Import
- Machine Set support for CABINET VISION | Paperless Traveller
- dbo.Rooms | RoomName field expanded to match CV room name character limit
+Label App
- Define Line Width for Part: Graphic on Label
Machine Catalog
- Combine Face and Back for two side simultaneous machining
